Wood Post Insulators
44
New Engl and ’s Agr i cul tura l Fence Exper t s
Mini J-Bolt
A rolling insulator allows conductors to
flow around corners and curves when
tension changes occur. One inch lag
screws directly into wood posts. For use
with low tension fence only. For a high-
tensile equivalent, use product IJBOLT.
IJMINI 0.12 lbs.
$0.99
Insulator Tubing, 50'
This black polyethylene tubing is
designed to insulate high-tensile wire
intersections such as brace wires from
line wires.
Not designed for high-
strain applications such as high-
tensile corners and ends
- instead see
Supatube on page 48.
II50 0.9 lbs.
$11.15
Spiralator Tube Insulator 4
"
The Spiralator is a clever 4
"
tube insulator that can be applied to a wire
without cutting it. Great for brace wires or where an insulator needs to be
installed on existing fence. This insulator is also available in a 50
'
coil for
creating custom lengths. Spiralator insulators are not recommended for
high-strain uses such as around end and corner posts.
IST4 .04 lbs. 4" tube
$0.30
IST50 2.8 lbs. 50' coil
$27.35
J-Hook Anchor
1/2" x 6" lag for use with PI20 & PI20B insulators. Excellent
anchor for supporting sap line support wires. Hot-dip galvanized.
IJHOOK 0.25 lbs. $1.97
Insulators
Insulators are a necessity with electric fencing and there are
insulator options for any scenario one could encounter in
the field. We carry many styles of insulators that provide
solutions for offsetting conductors along fences by attaching
to wood posts, steel T-posts, woven wire, chain link fence,
pipe, or U-posts. When selecting an insulator, be sure that
the insulator is the correct size/fit for your conductor. Please
note our large selection of fiberglass rods and rod insulators
begin on page 44.
Corner Roller
The insulated corner roller is ideal for
braid, rope, 1/2" tape or light gauge
wire (not for high-tensile). Unlike
conventional J-bolts, the conductor
cannot slip down and short out. For
wood posts only.
ICRB 0.06 lbs.
$1.49
J-Bolt
The 5.5" long J-bolt rolling insulator
is ideal in high-tensile fence corners
or for ending fence lines on wood
posts or trees. Replaceable donut insulator available in black or white.
IJBOLT 0.27 lbs.
$2.49
