To Order Ca l l Tol l Free : 1-855-FARMFENCE (855-327-6336)
37
EnduraSoft
®
6.0
Twisted ropes for permanent electrified fences.
Made of polyester (soft to the touch). Can last
up to 25 years. High conductivity. Made of 3
cables of twisted polyester fibers into which 3
tinned copper and 3 stainless steel filaments are
intertwined.
CPE660 660' 12 lbs.
$90.00
CPE1320 1320' 22 lbs.
$176.00
Low-Tension Conductors
IntelliTwine
™
Easy to wind/rewind onto reels. Great for
portable fences for sheep and cattle. Has 3
stainless steel and 3 tinned copper filaments and
24 polyethylene monofilaments.
CPP660 660' 2 lbs.
$22.00
CPP1320 1320' 4 lbs.
$42.00
CPP2000 2000' 5 lbs.
$66.00
IntelliBraid
™
6.0
Comprised of 4 tinned copper filaments twisted
around braided polyester filaments. Resistant to
UV light degradation. Life span of up to 25 years.
CPB660 660' 11.6 lbs.
$99.00
CPB1320 1320' 23.4 lbs.
$198.00
IntelliRope
®
PE, 4.5
Comprised of 3 tinned copper, 3 stainless
steel filaments and polyethylene filaments.
Particularly good for humid climates because
polyethylene resists mildew.
CPR4660 660' 5 lbs.
$39.00
CPR41320 1320' 9.2 lbs.
$76.00
Conductor Comparison Chart
Conductor
Probable
Years of Life
Breaking
Strength
Diameter
or Width
Portability
Resistance
Ω per 1000 ft.
Animal
Visibility
Approximate
Cost per ft.
IntelliBraid™
25
1800 lbs.
1/4"
fair
48 Ω
good
15¢
EnduraSoft® 6.0
25
1800 lbs.
1/4"
fair
41 Ω
very good
13.3¢
IntelliRope® PE 6.0
10
1200 lbs.
1/4"
good
41 Ω
very good
8.6¢
IntelliRope® PE 4.5
10
750 lbs.
3/16"
very good
41 Ω
good
5.7¢
IntelliTwine™
5
240 lbs.
2.2 mm excellent
41 Ω
fair
3.3¢
MaxiShock™
15
160 lbs.
1.7 mm
good
19 Ω
poor
8.4¢
IntelliTape™
5
200 lbs.
1/2"
good
36 Ω
very good
5.0¢
A
conductor carries current in a fence line to provide an electric shock. The conductor you choose depends on factors such
as visibility, longevity, cost, and conductivity. A combination of two or more types of conductors can be used to maximize
effectiveness and affordability of the electric fence. Wellscroft can help determine which conductor is best for you. In many cases,
we recommend a smooth high-tensile wire for a permanent perimeter fence. It maintains strong conductivity for many years, is
inexpensive, and comes in several strengths, gauges, and coating types.
IntelliRope
®
PE, 6.0
Excellent built in elasticity with a life span of
up to 10 years. Heavier, stronger and more
expensive than 4.5 mm rope.
CPR660 660' 8.2 lbs.
$58.00
CPR1320 1320' 18 lbs.
$114.00
IntelliTape
™
Highly visible ½” narrow tape due to contrasting
colors. Effective for deer, horses and cattle.
Life span of at least 5 years depending upon
installation, and animal/wind/snow/ice/
vegetation pressure.
CPT330 330' 2 lbs.
$17.00
CPT660 660' 3 lbs.
$33.00
CPT1320 1320' 6 lbs.
$66.00
